Objective module assembly: two 3 mm diameter, 6 mm FL achromat lenses with the flat (less curved) side facing the bottom of the objective, secured with M1 x 3 mm screws.
Source: ACAN 2023 Miniscope Assembly Tutorial (Federico N. Sangiuliano Jimka, Miniscope team).
