Emission module: 4 mm diameter, 10 mm FL achromat tube lens and T495LpXR dichroic mirror placement. The coated side of the dichroic faces the incoming light from the objective.
Source: ACAN 2023 Miniscope Assembly Tutorial (Federico N. Sangiuliano Jimka, Miniscope team).
